Passion Fruit Juice Machine|Passion Flower Juice Machine|Passionfruit Pulping Machine

  • Support Customization: Yes
  • Brand: Gelgoog
  • Warranty Time:12 Months
  • Country Of Origin:China
  • Payment: T/T, L/C, Trade Assurance, Western Union
The passion fruit juice machine is used to get passion juice. At the same time,the passion fruit juice machine can make the passion fruit pulp, seeds can be separated in order to get pure passion fruit juice.
 According the feature of passion fruit,the juice machine is special designed for passion fruit juice combine with advanced technology.
If using the passion  fruit juice machine,we don’t need to sort passion fruit for their size and we have high extraction juice rate.
working principle:
The passion fruit juice machine consists of a hopper, crusher, separator tube, sub-seed tube, transmission, chassis and other components. When start working,the passion fruit first passes through the crusher, and then into the separator tube to separate skin, juice. Pulp and seeds into the seed sub-cylinder, and then the separate the juice,pulp and seeds. So that we can achieve the purpose of separation of three things and get pure passion fruit juice.

Capacity :1 T/H, 5 T/H

passion extractor machine work video: click here :passion fruit juice video.

Leave Message  for Quotation

passion fruit juice machine| passion fruit pulping machine
Technical Data
Model GG-1 GG-5
Power 2.2kw 4.0kw
Capacity 1T/H 5T/H
Dimension 1900*670*1695mm 2500*1000*1800mm

Q.Can I have the video of the fruit juice machine ?
A.Yes, of course. we share machine video freely. Contact for it.
Q:What if customers know little about import processing?
 A: Our factory has rich experience in export.We will assist customers with needs step by step, from placing orders to receiving poutry feed manufacturing equipment.
Q: What's the material of the passion fruit machine?
It is made of stainless steel. It is in line with national standards. We also can customer make according your detail demands.
